Fiber Optic Voice link with Telephone Hand set
Transmitter : one fiber optics LED having peak wave length of emission 660 nm
Receiver : one fiber optic photo detector
Drivers : Analog
AC Amplifier : 1 No.
Filter : 1 No.4th order Butterworth 3.4KHz cut-off frequency
Patch cord
2mm patch cord
4mm patch cord
16A Terminal
32A Terminal
Single stand wire coil
Phase Shift Keying Trainer Kit – PSK - Modulation and Demodulation
Carrier Signal Generator - Sine 10KHz
Data generator - Using decade counter 7490
Power supply inbuilt (±5V/500mA)
ASK Modulation and Demodulation kit
Carrier Signal Generator - Sine 10KHz
Data Generator - 4 different data inputs
Power supply inbuilt (±5V/500mA)
Closed wood box
Input AC230V
Frequency Shift Keying Trainer Kit – FSK- Transmitter and Receiver
Clock Generator - 10KHz
Data Generator - 4 different data’s
FSK Modulation using IC 7400
FSK Demodulation included
Power supply inbuilt
Closed wood box (±5V/500mA)
Input AC230V
Digital Modulation and Demodulation Kit - ASK, FSK, PSK with source
±5V, 15V/500mA DC Power Supply
Carrier signal output
Data signal output
Data signal with 8 bit selective switch
ASK modulator & demodulator
PSK modulator & demodulator
FSK modulator & demodulator
Patch cards
Wood Box (Closed Type)
TDM Trainer Kit - Time division multi flexure
Digital Time Division Multiplexing and De-multiplexing
8 Bit data generator
Clock and address generator
8:1 Multiplexer
1:8 De-multiplexer
Power supply inbuilt (±12V/500mA, +5V/500mA)
Input AC230V
Closed wood box
Fiber Optic Analog Link - Transmitter & Receiver
Fiber optic cable - 1 meter - 1 No.
Fiber optic cable - 3 meter - 1 No.
Signal source inbuilt
Power supply inbuilt
Closed wood box
Input AC230V
Fiber Optic Digital Link - Transmitter and Receiver
Built in clock Generator
Fiber optic cable 1 meter - 1No.
Power supply inbuilt
Closed wood box
Input AC230V
Fiber Optic Digital Link - Transmitter and Receiver
Built in clock Generator
Fiber optic cable 1 meter - 1No.
Power supply inbuilt
Closed wood box
Input AC230V
Fiber Optic Digital Link - Transmitter and Receiver
Built in clock Generator
Fiber optic cable 1 meter - 1No.
Power supply inbuilt
Closed wood box
Input AC230V
